When learning how to create databases, you most likely learned how to use auto-incremented values for identifiers. These automatically generated values are extremely useful as they provide a unique, simple and usually small identifier for a row in the table. They can then be used to join tables and create a relational structure between your entities.

In a Doctrine ORM entity, this usually looks like this:

/**
 * @var int|null
 *
 * @ORM\Id
 * @ORM\GeneratedValue
 * @ORM\Column(type="integer", options={"unsigned": true})
 */
private $id;

This technique, however, has several drawbacks when badly used. The biggest one being that if you rely on an auto-incremented value in your URLs, anyone can know how many resources you have, which might not be something you would like your competitors to know.

Moreover, by using an auto-incremented value in your URLs, you give the possibility to your users to scrap your whole website easily, by writing a simple script accessing /users/1, /users/2, /users/3, …

While this may not be a huge problem for some entities, it is important to have control over the possibility for users to scrap your website or not.

That’s where UUIDs are useful.

Using UUIDs with Doctrine

UUIDs, or Universally Unique IDentifiers, are a way to generate numbers that are (almost) unique, wherever they are generated, without the need of a central authority to synchronize the unicity (ie. without the need of a database knowing the number of rows before generating a value).

UUIDs are extremely useful in many contexts and for many reasons, especially because 5 versions of UUIDs exist to cover different use-cases. Have a look at https://en.wikipedia.org/wiki/Universally_unique_identifier to learn more about them.

In our context, UUIDs are a great way to avoid exposing auto-incremented numbers in our URLs: instead of /users/1/tgalopin, we could have URLs like /users/c11ed9b0-e060–4aec-b513-e17c24df2c70/tgalopin.

To use UUIDs with Doctrine, I recommend you to use the Ramsey UUID Doctrine package: https://github.com/ramsey/uuid-doctrine. This package will let you configure Doctrine fields as UUIDs, storing them the best way possible in your database. Moreover, if you use Symfony Flex, you won’t even have to configure anything as the recipe will do it for you!

Once installed, you will be able to create fields like this one:

/**
 * The internal primary identity key.
 *
 * @var UuidInterface|null
 *
 * @ORM\Column(type="uuid", unique=true)
 */
protected $uuid;

And populate this field with the different versions of UUID, for instance with the version 4 (random UUID):

$this->uuid = Uuid::uuid4();

The problems of UUIDs and how to solve them

While UUIDs are a great way to get unique and difficult-to-scrap identifiers, there are still two main issues when using them:

• potential performance loss when using UUID as primary keys

• lack of readability of the resulting URLs

Performance of UUID primary keys

If you use UUIDs as primary keys and if your database storage is not able to handle them properly (you should use PostgreSQL ;) ), you will get strings as primary keys. Having strings in WHERE filters, indexes and join queries is a big performance issue due to the size and complexity of the data structure.

This can be improved by a pattern commonly used with UUIDs: having both an auto-incremented integer as primary key and a UUID as a unique field in your entity. This allows you to use the UUID for public display and rely on the auto-incremented integer in joins for performance.

To use this pattern in Doctrine, I create the following trait in most of my applications:

namespace App\Entity;

use Doctrine\ORM\Mapping as ORM;
use Ramsey\Uuid\UuidInterface;

trait EntityIdTrait
{
    /**
     * The unique auto incremented primary key.
     *
     * @var int|null
     *
     * @ORM\Id
     * @ORM\Column(type="integer", options={"unsigned": true})
     * @ORM\GeneratedValue
     */
    protected $id;

    /**
     * The internal primary identity key.
     *
     * @var UuidInterface
     *
     * @ORM\Column(type="uuid", unique=true)
     */
    protected $uuid;

    public function getId(): ?int
    {
        return $this->id;
    }

    public function getUuid(): UuidInterface
    {
        return $this->uuid;
    }
}

// In another entity:
class User
{
    use EntityIdTrait;
    // ...
}

Readability of URLs

When using UUIDs in URLs, a large part of the URL is not readable by the user anymore. While it’s not a major drawback, having a URL like /user/1/tgalopin is definitely much better than having /user/c11ed9b0-e060–4aec-b513-e17c24df2c70/tgalopin for the users of your application.

To improve this, there are several ways:

• we could try to find a smaller data structure than UUIDs (but the support of UUIDs is really great among many programming languages)


• we could use only a portion of the UUID (but we would risk to encounter a lot of conflicts)


• or we can encode the UUID in a format more suited to URLs

In my opinion, the last option is the best compromise between readability and compatibility, so I looked for different encoding format that would match the readability needed of an URL.

The format you may have thought about when you read the previous paragraph is base64. It’s a great format to express data in a more compact way than hexadecimal, but I didn’t like the possibility to have =, + and / into my identifiers: it didn’t seem to match the need of readability of the URL.

That’s why I looked at base32: base32 has less characters and therefore is slightly longer than base64, but it’s much more suited to an URL as it only has alphanumerical characters.

To use base32 encoded UUIDs, I created several useful tools in my Doctrine application:

A UuidEncoder, which uses the GMP extension to encode and decode UUIDs:

namespace App\Doctrine;

use Ramsey\Uuid\Uuid;
use Ramsey\Uuid\UuidInterface;

class UuidEncoder
{
    public function encode(UuidInterface $uuid): string
    {
        return gmp_strval(
            gmp_init(
                str_replace('-', '', $uuid->toString()),
                16
            ),
            62
        );
    }

    public function decode(string $encoded): ?UuidInterface
    {
        try {
            return Uuid::fromString(array_reduce(
                [20, 16, 12, 8],
                function ($uuid, $offset) {
                    return substr_replace($uuid, '-', $offset, 0);
                },
                str_pad(
                    gmp_strval(
                        gmp_init($encoded, 62),
                        16
                    ),
                    32,
                    '0',
                    STR_PAD_LEFT
                )
            ));
        } catch (\Throwable $e) {
            return null;
        }
    }
}

A Twig extension to create links:

namespace App\Twig;

use App\Doctrine\UuidEncoder;
use Ramsey\Uuid\UuidInterface;
use Twig\Extension\AbstractExtension;
use Twig\TwigFunction;

class UuidExtension extends AbstractExtension
{
    private $encoder;

    public function __construct(UuidEncoder $encoder)
    {
        $this->encoder = $encoder;
    }

    public function getFunctions(): array
    {
        return [
            new TwigFunction(
                'uuid_encode',
                [$this, 'encodeUuid'],
                ['is_safe' => ['html']]
            ),
        ];
    }

    public function encodeUuid(UuidInterface $uuid): string
    {
        return $this->encoder->encode($uuid);
    }
}

A repository trait to easily find an entity by encoded UUID (note that the property needs to be populated by the repository using the trait):

namespace App\Repository;

use App\Doctrine\UuidEncoder;

trait RepositoryUuidFinderTrait
{
    /**
     * @var UuidEncoder
     */
    protected $uuidEncoder;

    public function findOneByEncodedUuid(string $encodedUuid)
    {
        return $this->findOneBy([
            'uuid' => $this->uuidEncoder->decode($encodedUuid)
        ]);
    }
}

This suite of tools allows me to get URLs like this one:

/users/3xv5LDIdusDxM77x0MW8bI/tgalopin

The best of both worlds!
